Parameters

• Model

  BT STICK 250-1

• Power supply voltage(V)

  90-275

• Power frequency (Hz)

  50/60

• MMA

  TIG

• Effective current (A)

  43.6

  31.2

• Rated input current (A)

  56.3

  40.3

• Rated Input Power (KW)

  129.9

  9.2

• Duty Cycle(40℃ 10Min)

  60% 250A 100% 195A

• Welding Current Range(A)

  10-250

• No Load Voltage(V)

  69

• Efficiency (%)

  88

• Power factor

  0.66

  0.64

• Insulation Class

  F

• Protection Class

  IP21S

• Cooling

  AF

• Net Weight(Kg)

  13

• Dimensions(mm)

  550*190*360
