Parameters

• Model

  BT STICK 250-3

• Power supply voltage(V)

  3~400

• Power frequency (Hz)

  50/60

• MMA

  TIG

• Effective current (A)

  14.2

  10.1

• Rated input current (A)

  18.3

  13.0

• Rated Input Power (KW)

  12.7

  9.0

• Duty Cycle(40℃ 10Min)

  60% 250A 100% 195A

• Welding Current Range(A)

  10-250

• No Load Voltage(V)

  66.8

  12.0

• Efficiency (%)

  87.4

• Power factor

  0.69

  0.66

• Insulation Class

  F

• Protection Class

  IP21S

• Cooling

  AF

• Net Weight(Kg)

  13.7

• Dimensions(mm)

  550*190*360
