Parameters

• Model

  MZ-1000

  MZ-1250

• Power supply voltage(V)

  3~400

  3~400

• Power frequency (Hz)

  50/60

  50/60

• Rated input current (A)

  78.1

  97.6

• Duty Cycle(40℃ 10Min)

  100% 1000A

  60% 1250A 100% 1000A

• Welding Current Range(A)

  20~1000

  20~1250

• No Load Voltage(V)

  78

  78

• Efficiency (%)

  84

  84

• Power factor

  0.9

  0.9

• Insulation Class

  F

  F

• Protection Class

  IP21S

  IP21S

• Cooling

  AF

  AF

• Net Weight(Kg)

  86

  86

• Dimensions(mm)

  800*350*940

  800*350*940

• Rated input power (KVA)

  52.5

  65.6
